120 in. x 80 in. Black Aluminum Bifold Patio Door
ROZAN
120 in. x 80 in. Black Aluminum Bifold Patio Door
120 in. x 80 in. Black Aluminum Bifold Patio Door
- Product size
- 120 in. x 80 in.
- Required rough opening
- 120½ in. W × 80½ in. H
- Jamb depth
- 3 in.
Bottom-supported track: Panels sit on the bottom track rather than hanging from the header.
Outside view: Left / right is viewed from the exterior. Match the opening option selected above.
Confirm fit with your installer. Measuring guide
Couldn't load pickup availability
Product overview
−
Open Your Space
Turn a 10-foot-wide opening into a flexible indoor-outdoor transition with the ROZAN 120 in. x 80 in. (approximately 10 ft. x 6 ft. 8 in.) Black Aluminum Bifold Patio Door. Available in 3- or 4-panel configurations, this size provides more choice in how the opening is divided and operated.
The black aluminum frame creates a strong architectural outline around the expansive glass.
Required Rough Opening: 120½ in. W × 80½ in. H
How to Measure Your Opening →
Product Highlights
| Door Size: | 120 in. W x 80 in. H |
|---|---|
| Approximate Size: | 10 ft. W x 6 ft. 8 in. H |
| Panel Configuration: | 3 or 4 Panels |
| Opening: | Left, Right, 1L3R, or 1R3L |
| Frame: | Thermally Broken Aluminum |
| Frame Color: | Black |
| Glass: | Low-E Insulated Tempered Glass |
| Operation: | Folding / Outswing |
| Opening Direction: | Left or Right, determined when viewed from the exterior |
| Rough Opening: | 120½ in. W × 80½ in. H |
| Also Available in: | White |
Specifications
| Frame & finish | |
|---|---|
| Frame Material | Aluminum |
| Aluminum Alloy | 6063-T5 |
| Aluminum Thickness | 2.0 mm |
| Frame Construction | Thermally Broken |
| Finish | Powder-Coated |
| Glass | |
| Glass Type | Low-E Insulated Tempered Glass |
| Glass Build | 5mm Low-E + 27A Argon + 5mm Clear Tempered |
| Operation & hardware | |
| Operation | Folding |
| Swing | Outswing |
| Jamb depth (frame) | 3 in. |
| Track Type | Low Track |
| Track Height | 0.8" (21 mm) |
| Track Depth | 2.56" (65 mm) |
| Locking System | Multipoint Locking System |
| Hardware | Heavy-Duty Adjustable Hardware |
| Energy performance | |
| U-Factor | 0.26 |
| SHGC | 0.32 |
| Visible Transmittance | 0.35 |
| Air Leakage | 0.2 |
| Condensation Resistance | 51 |
Warranty & support
−
Frame: 10 years
Glass: 2 years
Hardware: 2 years
Coverage is subject to eligibility, exclusions and your order documentation.
View warranty termsNeed help choosing?
Discuss sizing, configuration, or delivery with ROZAN.
Get a product quote Call ROZAN · (949) 943-3330Product Image Notice: Product images are for reference and may show placeholder components. Handle and hinge designs may vary from the images shown due to ongoing manufacturer product updates. Final hardware may differ in appearance while maintaining the specified product configuration.
